SC6151:  5.0 megapixel indoor box PoE IP camera
Description:
SC6151 is 5.0 megapixel indoor box PoE IP camera, it use 1/2.5" 5.0 Megapixels Progressive Scan Aptina CMOS sensor and H.264 compression algorithm, support WDR (wide dynamic range ), 3D Noise Reduction, video rotation and low-light function, can get perfect image in a variety of lighting conditions.
● 1/2.5" 5.0 Megapixels Progressive Scan Aptina CMOS.
● H.264 & MJPEG dual-stream encoding
● Max 5.0 megapixel 12fps@2592x1944, and 3.0 megapixel 20fps@2048x1536, 2.0 megapixel 25/30fps@1080P (1920x1080).
● WDR, intelligence 3D noise reduction, AWB, AGC, BLC
● Multiple network monitoring: Web viewer, CMS, Smart phone
● Micro SD Card Slot (max 64GB)
● Support image rotation 90° or 270°
● Built in POE
Options:
● AC/DC Adapter
● IR-Cut
● Audio & alarm Interface Board

Demo Picture:
The following pictures have been resized,  you can click the link to view the original big pictures (100% size).
5 megapixel IP camera demo picture outdoor
5 megapixel IP camera demo picture outdoor
5 megapixel IP camera demo picture outdoor
5 megapixel IP camera demo picture outdoor


Products:
Model
ICR
POE
A/V
Lens
SC6151
No
Yes
No
No
Image Sensor
1/2.5" 5.0 Megapixels Progressive Scan Aptina CMOS
Effective Pixels
2592x1944
Scanning System
Progressive
Electronics Shutter Speed
Auto (1/25,1/30 ~ 1/10000s)
Min. Illumination
0.5Lux/F1.2 (Color), 0.05Lux/F1.2(B/W);
S/N Ratio
>50dB
Video Output
(“-AV” only) 1 Channel BNC (1.0Vp-p,75Ω)
Camera Features
Day/Night
Color / B/W
Backlight Compensation
BLC / HLC / WDR (digital)
White Balance
Auto
Gain Control
Auto
Noise Reduction
2D, 3D
Privacy Masking
Up to 4 Areas
Lens
Lens Type
C/CS
Video
Compression
H.264 / MJPEG
Resolution
2592x1944, 2048x1536 ; 1920x1080; 640x352, 320x240
Frame Rate
Preferred Stream
2592x1944 (1~12fps),
2048x1536 (1~20fps),
1920x1080(1~25/30fps),
Alternate Stream
640x320, 320x160, 160x112 (1~25/30fps)
Bit Rate
32KB ~16Mbps, support VBR, CBR
Audio     (“-AV” only)

Compression
G.711a / G.711U, G.726
Interface
1 channel Input, 1 channel Output
Network
Ethernet
RJ-45 (10/100Base-T)
Protocol
IPv4/IPv6, HTTP, TCP/IP, UDP, RTP, RTCP, UPNP, RTSP, SMTP, NTP, DHCP, DNS, PPPOE, DDNS, FTP, SNMP,ONVIF
ONVIF
ONVIF Ver. 2.3
Max. User Access
10 users
Smart Phone
iPhone, iPad, Android, Symbian
Auxiliary Interface
Memory Slot
Micro SD, Max 64GB
Alarm (“-AV” only)
1channel Input, 1 channel Output
General
Power Supply
DC12V, POE (802.3af)
Power Consumption
≤3W
Working Environment
-20 ℃ ~ 60
Dimensions
152mm ×86mm ×56mm
Weight
0.7KG

2.0 Megapixel 1080P Sony Exmor CMOS HD IP Box Camera interface

2.0 Megapixel 1080P Sony Exmor CMOS HD IP Box Camera interface

I/O interface definition:
1
1A: ALARM Output
4
G: ALARM Input GND
2
1B: ALARM Output
5
T-: RS485 control output +
3
IN: ALARM Input
6
T+: RS485 control output -
